High-Load Hammer Drive Anchor Bolt TUB-Q

Product Advantages

Rapid, Tool-Free Installation

The Hammer Drive Anchor Bolt TUB-Q requires no complex tools (e.g., electric drills, glue guns)—installation is completed in seconds via simple hammering. The streamlined process (drilling → hole cleaning → inserting anchor → hammering) boosts on-site efficiency, making it a top choice for rapid installation anchor projects.

Exceptional Load-Bearing Capacity

Built on the mechanical expansion principle, the anchor’s tail expands when hammered, forming a "key-shaped lock" with the substrate. This design delivers outstanding tensile strength and shear strength, qualifying it as a high load capacity anchor for heavy-duty uses like curtain wall keels and heavy equipment bases.

Superior Vibration & Fatigue Resistance

The expansion body of the concrete hammer drive anchor tightly meshes with the hole wall, preventing loosening in dynamic environments (e.g., bridges, factories). Its robust structure ensures long-term stability under constant vibration, outperforming standard anchors in fatigue resistance.

Broad Substrate Compatibility

This anchor works seamlessly with C25-C60 concrete, dense natural stones (granite, marble), and even slightly cracked concrete (per certification standards). Its versatility makes it a flexible multi-substrate anchor for diverse construction needs.

Safety & Cost Efficiency

Free of chemical adhesives, the Hammer Drive Anchor Bolt TUB-Q is eco-friendly and avoids pollution risks. It also has excellent fire resistance (heat-resistant metal material) for fire-sensitive areas. With a lower unit price than chemical anchors and minimal labor/equipment costs, it’s an affordable hammer drive anchor for budget-conscious projects.

Detail Data

The Hammer Drive Anchor Bolt TUB-Q offers multiple models to match project requirements. Key specifications include:

Model TUB-Q 11*13 M6: Drilling diameter 11mm, reaming diameter 13.5mm, anchorage depth 13mm, screw diameter M6, minimum plate thickness 25mm.

Model TUB-Q 11*16 M6: Same drilling/reaming diameters as the 11*13 M6, with anchorage depth 16mm and minimum plate thickness 30mm.

Model TUB-Q 11*18 M8: Drilling diameter 13mm, reaming diameter 15.5mm, anchorage depth 18mm, screw diameter M8, minimum plate thickness 35mm.

All models are available in 304(A2), 316(A4), or 210 stainless steel, ensuring compatibility with low to high corrosion-resistance demands.

Applications

Building Facades

Ideal for securing stone/metal curtain wall mullions and reinforcing corner joints. The Hammer Drive Anchor Bolt TUB-Q withstands high wind loads and outdoor elements.

MEP Installation

Used for anchoring pipe supports, duct hangers, and equipment bases. It provides reliable hold for HVAC, plumbing, and electrical systems.

Steel Connections

Links steel beams, stairs, and platforms to concrete structures, delivering the strength needed for structural integrity in commercial and industrial buildings.

Suitable for noise barriers, traffic signs, and guardrail bases. Its durability ensures long-term performance in public infrastructure.

Service & Support

TEDUN offers comprehensive support for the Hammer Drive Anchor Bolt TUB-Q:

Customers can inquire about product details, request custom quantities, or add items to the basket via our user-friendly platform.

Social sharing tools (Facebook, Twitter, WhatsApp) facilitate project collaboration with teams or suppliers.

All anchors undergo strict quality testing to meet industry standards, with full traceability for material sourcing.

For bulk orders or technical consultations (e.g., installation guidance), our dedicated team provides timely assistance.
